Neuropathic Reconstruction

MIDFOOT NAILS & BEAMS

Watch Video
Contact Your Rep
Share

The REDEMPTION™ Midfoot Nail and Beams System has been designed to address the unique demands of advanced midfoot reconstruction. This system focuses on treating cases such as neuropathic deformity requiring arthrodesis of the medial and lateral columns, with or without corrective osteotomies.

Patients with poor quality, soft bone (e.g. Charcot), require implants specifically designed to deliver strength and maintain purchase in these difficult cases. The REDEMPTION™ Midfoot Nail and Beams System have been designed to specifically address these patients, while providing easy to use instrumentation that assists in attaining reproducible results.

REDEMPTION™ Midfoot Nail and Beams System may be used for definitive treatment in a singular manner, or used in conjunction with ancillary fixation such as external fixation, additional beams, plates, or contact casting until bony fusion has occurred.

REDEMPTION™ Midfoot Nail & Beams System Features

POWERFUL NEUROPATHIC RECONSTRUCTION
REDEMPTIONTM features both 7.5mm and 8.2mm Midfoot Nails to address a variety of patient anatomies
Comprehensive sizing of: 5.0mm, 6.5mm, and 8.0mm partially and fully threaded beams to address advanced reconstruction needs
Designed to achieve maximum compression through thread placement and pitch differential
All Beams and Nails are cannulated and made from Ti6Al4V titanium alloy, type II anodization

REDEMPTION™ Beam Features

FOUR POWERFUL MODES OF COMPRESSION
5.0 MM
  • Lengths: 35mm to 130mm by 5mm increments
  • Fully and partially threaded options
  • Taper on head is 20% of implant length
  • Variable Partial Thread Length: Proximal Threads are 20% of overall length
  • Distal Thread Lengths: 16mm (35mm-100mm) and 32mm (105mm-130mm)
6.5 MM
  • Lengths: 40mm to 160mm by 5mm increments
  • Fully and partially threaded options
  • Taper on head is 20% of implant length
  • Variable Partial Thread Length: Proximal Threads are 20% of overall length
  • Distal Thread Lengths: 16mm (35mm-100mm) and 32mm (105mm-130mm)
8.0 MM
  • Lengths: 40mm to 160mm by 5mm increments
  • Fully and partially threaded options
  • Taper on head is 20% of implant length
  • Variable Partial Thread Length: Proximal Threads are 20% of overall length
  • Distal Thread Lengths: 16mm (35mm-100mm) and 32mm (105mm-130mm)

REDEMPTION™ Midfoot Nail Features

SMART AND STABLE RECONSTRUCTION
7.5 MM
  • Lengths: 50mm to 160mm by 5mm increments
  • Thread Lengths on Proximal End:
  • 10mm for 50mm-65mm length implants
  • 20mm for 70mm-160mm length implants
  • Thread Lengths on Distal End:
  • 10mm for 50mm-65mm length implants
  • 20mm for 70mm-160mm length implants
8.0 MM
  • Lengths: 50mm to 160mm by 5mm increments
  • Thread Lengths on Proximal End:
  • 10mm for 50mm-65mm length implants
  • 20mm for 70mm-160mm length implants
  • Thread Lengths on Distal End:
  • 10mm for 50mm-65mm length implants
  • 20mm for 70mm-160mm length implants

Resources

SURGICAL TECHNIQUE

Download

SALES SHEET

Download

POWERFUL NEUROPATHIC RECONSTRUCTION

Learn more about Vilex’s newest addition to our neuropathic reconstruction product line - REDEMPTIONTM.

REDEMPTIONTM Midfoot Nail and Beams Nails have been designed to be a powerful, comprehensive solution for Charcot patients - all while providing easy to use instrumentation that assists in attaining reproducible results.
