RECON LOCKING PLATING SYSTEM
REIMAGINED RECON PLATING
About
ALPHALOK™ RECON
The ALPHALOK™ RECON Plating System provides a comprehensive range of anatomically contoured plates specifically designed for the reconstruction or arthrodesis of the fore and midfoot.
ALPHALOK™ features low-profile 1.3mm, Titanium Alloy Ti6AI4V plates that accept 2.7mm and 3.5mm polyaxial locking screws that can be angled ±15° for a total range of 30°.
Additionally, ALPHALOK RECON™ Fibula Plates Accept 4.0mm non-locking Syndesmosis screws.
ALPHALOK™ features low-profile 1.3mm, Titanium Alloy Ti6AI4V plates that accept 2.7mm and 3.5mm polyaxial locking screws that can be angled ±15° for a total range of 30°.
Additionally, ALPHALOK RECON™ Fibula Plates Accept 4.0mm non-locking Syndesmosis screws.
ALPHALOK™ RECON Features
RECONSTRUCTION & ARTHRODESIS REIMAGINED
Low profile 1.3 mm plating designed to reduce soft tissue irritation
Innovative screw sizing options of 2.7mm and 3.5mm, which are universally accepted in all plate holes
Polyaxial locking and non-locking screws that can be angled ±15° for a total range of 30°
Comprehensive range of anatomic and universal plate options to address unique needs during reconstruction
ALPHALOK™ RECON Locking Technology
POWERFUL RECONSTRUCTION, MADE SIMPLE
ALPAHLOK™ RECON Plating is designed to universally accept 2.7mm and 3.5mm screws in all plate hole options.
ALPHALOK™ RECON plates also include oblong holes in order to achieve powerful compression during fusions.
To help improve ease of use and reduce OR time, ALPHALOK™ features a modular tray system with color-coded implants and instrumentation. All screws are also inserted with the same T10 Driver.
*4.0mm Sydesmosis Screws are on inteded for use with ALPHALOKTM RECON Fibula plates
ALPHALOK™ RECON Plating Options
DELIVERING THE POWER OF VERSATILITY
Small MTP Plates
Description
Left 0° - 40mm
Left 5° - 40mm
Left 10° - 40mm
Right 0° - 40mm
Right 5° - 40mm
Right 10° - 40mm
Medium MTP Plates
Description
Left 0° - 45mm
Left 5° - 45mm
Left 10° - 45mm
Right 0° - 45mm
Right 5° - 45mm
Right 10° - 45mm
Large MTP Plates
Description
Left 0° - 53mm
Left 5° - 53mm
Left 10° - 53mm
Right 0° - 53mm
Right 5° - 53mm
Right 10° - 53mm
Straight MTP Plates
Description
Left - 48mm
Right - 48mm
Revision MTP Plates
Description
Left - 62mm
Right - 62mm
Medial Column Plates
Description
Left - 75mm
Left - 85mm
Right - 75mm
Right - 85mm
Naviculocuneiform Plates
Description
Universal - 28mm
Universal - 33mm
Talonavicular Plates
Description
Universal - 28mm
Cotton & Evans Plates
Description
Universal - 8mm
Universal - 10mm
Universal - 12mm
Universal Plates
Description
Left - 21mm
Left - 53mm
Right - 21mm
Right - 53mm
Left - 31mm
Left - 61mm
Right - 31mm
Right - 61mm
Left - 39mm
Universal - 87mm
Right - 39mm
Universal - 115mm
Lapidus L Plates
Description
Left - 40mm
Right - 40mm
Left - 50mm
Right - 50mm
Left - 60mm
Right - 60mm
Lapidus Plates
Description
Universal - 35mm
Universal - 42mm
Universal - 50mm
Straight Plates
Description
Universal - 4 Hole
Universal - 40mm
Universal - 5 Hole
Universal - 6 Hole
Universal - 35mm
Dog Bone Plates
Description
Universal - 28mm
Universal - 33mm
Tarantula Plates
Description
Universal - 8mm
Universal - 10mm
Universal - 12.5mm
Universal - 15mm
Straight Fibula Plate
Description
Universal Straight Plate - 5 Holes
Universal Straight Plate - 6 Holes
Universal Straight Plate - 7 Holes
Universal Straight Plate - 8 Holes
Universal Straight Plate - 9 Holes
Universal Straight Plate - 10 Holes
Fibula Plate
Description
X-Small, Left - 8 Holes
Small, Left - 9 Holes
Medium, Left - 10 Holes
X-Small, Right - 8 Holes
Small, Right - 9 Holes
Medium, Right - 10 Holes
PLATING REIMAGINED
Learn more about Vilex’s newest plating line, ALPHALOK™.
ALPHALOK™ is designed to deliver powerful, versatile reconstruction in the fore and midfoot - all with easy to use instrumentation for reproducible results.
